Add-on optics for different measuring geometries
JETI offers a variety of add-on optics to achive certain different measuring geometries.

Add-on optics for measurement of VR/AR glasses
JETI offers add-on optics to perform measurements of VR/AR glasses. These optics are only available for JETI specbos 2501 (equipped with focus add-on).

Standard diffusor
The pure specbos 2501 measures in spectral Radiance mode. It is possible to convert it into a spectral Irradiance meter by attaching a diffusor.

90° diffusor
The standard diffusor of the device acts in line to the device. If the Illuminance at a low height above a surface needs to be measured, then the 90° diffusor can be applied. It is also available with attenuation filters to extend the Illuminance measuring range.

In axis remote diffusor
If the measurement needs to be done in locations with limited space conditions then the remote diffusor can be used. It is a diffusor which is coupled to the spectraval device by an optical fiber bundle. The measurement is done in axis to the fiber bundle. Different fiber lengths are available.

90° remote diffusor
If the measurement needs to be done under limited space conditions and the in axis fiber coupled diffusor is not suited, then the 90° fiber coupled diffusor can be applied. Different fiber lengths are available.

Diffusors with attenuation filter
JETI specbos 2501 with its standard diffusor can measure up to about 1.500.000 lx (typical white LED spectrum). If it is necessary to measure higher Illuminances, then a special diffusor with additional attenuation filter can be used.

Dome
The dome is equipped with a glass dom and it is IP67 tested. It can be mounted on roofs or outside walls and allows a detection of the optical sky radiation.

Fast diffusors
If low Illuminance levels must be measured, then the measuring time will be long when using the standard diffusor of the device. It is possible to use “fast” diffusors, but only if the cosine matching of the diffusor is not of primary importance, e.g. in case of point like sources.

Dolby/realD filter cap pairs
The calibration of 3D projectors needs to be done through the right and left eye glasses. specbos 1211-2 can be equipped with caps containing the filters of Dolby and realD projection. The usage of these filter pairs allows a precise measurement of these 3D projection system.

Neutral density filter
JETI specbos 2501 can measure up to 100 000 cd/m². An additional neutral density filter allows to shift the measuring range towards higher Luminance levels.

VIS filter
JETI specbos 2501 can be equipped with a VIS filter to reduce its wavelength range to 350 … 780 nm. This is especially interesting for measurements with a low VIS intensity but much signal in IR or UV.

Integrating spheres
To extend the functionality of JETI specbos 2501 to Radiant flux measurements, JETI offers three different models of integrating spheres.

5 V power supply

5 V power supply with locked USBC

Bluetooth USB adapter

Carrying case/ bag

Fiber bundle attachment for SMA 905

Protective cap

Replacement battery for BT

Straylight protection tube
The straylight protection tube prevents the influence of surrounding light on Radiance measurements. It is mainly used for display measurements. The fixed length of the tube is 16 cm.

Tripod

Stray light correction matrix
In order to reduce stray light in array spectroradiometers while taking advantage of their portability, JETI offers a stray light correction matrix.
